Regulator output
Here you can select your preferred output voltage: you can choose between 6.0V,
7.4V, 7.8V and unregulated output.
We recommend the 7.8V option even for HV servos, as this setting ensures that
your servos operate with constant torque and transit speed for a long period after
switching on. The higher voltage of the batteries, which is only present for a brief
period after charging, is reduced to a level which the battery can maintain for
longer.
•
Frame rate
The default setting for this is 16ms, at which all current servo types operate reliab-
ly. Digital servos can deliver better performance if you set the frame rate to 12ms.
Older analogue servos, on the other hand, may become hot if the frame rate is set
too low, and will not be able to find their commanded position accurately.
•
Capacity reset channel
Enter a channel at this point which you wish to use to reset the consumed battery
capacity. The capacity is reset when the selected channel is moved to +100%.
•
Language
Select German or English as menu language.
•
Reset options
This menu point takes you to a sub-menu in which you can reset various settings
individually or jointly.

6. SETUP ASSISTENT

The Setup Assistant is designed to help you complete basic channel
and servo assignments quickly and easily. We recommend that you
continue to use the Setup Assistant even if you are very familiar with
the workings of PowerBox products. You should also use the Assistant
even if you (temporarily) do not wish to use an iGyroSAT.
On the one hand the Assistant simplifies operations, because the menu initially re-
fers to outputs in general terms, such as DIRECT-xy, but once you have completed
the Assistant it uses specific designations, for example, Right aileron ... etc.
On the other hand it is possible to retro-fit an iGyroSAT without having to re-program
the battery backer.
