Thundercomm Qualcomm Robotics RB5 Hardware User Manual page 39

39 CSI5_D0_P
41 CSI5_D0_M
43 CSI5_D1_P
45 CSI5_D1_M
47 CSI5_D2_P
49 CSI5_D2_M
51 CSI5_D3_P
53 CSI5_D3_M
55 GND
57 PMK8002_RF_CLK1
59 PMK8002_RF_CLK2
PIN RB5 Signals
2 GND
4 PCIE1_RX1_M
6 PCIE1_RX1_P
8 PCIE1_TX1_M
10 PCIE1_TX1_P
12 GND
14 PCIE2_REFCLK_M
16 PCIE2_REFCLK_P
18 PCIE2_RX0_M
20 PCIE2_RX0_P
22 PCIE2_RX1_M
24 PCIE2_RX1_P
26 PCIE2_TX0_M
28 PCIE2_TX0_P
30 PCIE2_TX1_M
32 PCIE2_TX1_P
34 GND
36 DSI1_CLK_P
38 DSI1_CLK_M
40 DSI1_D0_P
42 DSI1_D0_M
44 DSI1_D1_P
46 DSI1_D1_M
48 GND
50 DSI1_D2_P
52 DSI1_D2_M
54 DSI1_D3_P
56 DSI1_D3_M
58 GND
Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
Robotics RB5 Development Kit Hardware User Manual
Note
33
