Using Of Connectme - LX Navigation LX Mini Map User Manual

LX Navigation d.o.o LX Mini Map V 1.4 May 29 2011
th

9 Using of ConnectMe

ConnectMe is free ware program which makes possible to download data stored in the flight recorder which is
connected to the Mini Map. Uploading of declaration and TP data base is also possible.
The program is factory preloaded and should be started from LX Mini Map desk top.
Use Exit function of navigation program to access desk top. SeeYou Moile 4.01 makes possible to start Connect me
from Menu page.
After click on ConnectMe icon the program will start.
To establish communication following settings should be adapted as minimum:
-device selection
-COM 2
-Baud rate selection (this should meet flight recorder type) or auto
Note!
In some configurations is exceptionally used com 1, so select com 1 having such a configuration. Com port
designation you find on the label of the wiring.
The destination to SD card is factory set, so all downloads will be stored to the SD card.
