8.7.2 Airspace colours

To any airspace a colour can be delegated. The airspace patterns could be also filled or only lines will represent the
airspace. A special option outline only will designate airspace sections only with a thin black line. Suggested setting
is Patterns.
8.7.2.1

Determination of colours

The coulurs are connected to airspace classification (A,B, C ...). So the pilot is able to add any colur from the palette
to any class. Some special items are added to the classes as Glider sites, AAT sector and some other options.
Note!
CTR is defined as class in LK 8000, so if you want to use a special colour for CTR this shouldn't have a class
designation, otherwise will be threaded as all other items of the class. Unknown as class designator will also solve
the problem.
After click on Colours following window will open:
To alter colour click on the bar and the whole palette will be offered. After click on colour a pattern selection will
follow, select pattern. To remove patterns and to use only colored airspace borders, define any colour from the
palette and select white field in pattern.
