LX Navigation d.o.o LX Mini Map V 1.4 May 29 2011
th
3.1.2.2

LX remote

Zoom in (Enter)
Up/Down
Zoom out (Space)
Left/Right
Menu (character d) Vario control

3.2 LX Mini Map KB/V and SeeYou Mobile

The configuration builds a real Vario Navigation system, which consists of GPS source delivering GGA and RMC
NMEA data sentences. LX Mini Map and LX Vario unit are connected via LX system bus. As mentioned before LX
Mini Map includes also a microcontroller which main functions is to arrange data exchange between interfaces and
main computer. That's the reason why com2 and 38400 bps should be initialized obligatory.
Note!
It is important to enable Device as LX 1600 in Hardware option. After activation of this option two new setup
options of SeeYou Mobile will open, (LX 1600 (1) and LX 1600 (2)). Using of COM 2 is obligatory
