6.1 Remote Setup

Remote Setup
Modbus Info
Modbus Setup
Auto timing
Analog output
Datalogger
Select:

6.1.1 Modbus

Info
The following information is available:
Indication
TxD buffer
RxD buffer
Device address ecom-ST device address
Setup
Parameter
Device address
Current values
Stored values
The following settings can be made:
32
Modbus, time control and analog outputs
(option) can be configured in the Remote Setup
menu. The menu item "Modbus Info" enables
the control of the Modbus data sent and
received. The menu item "Data logger" can be
used to record measured values on a memory
card.
Meaning
Received data
Sent data
Meaning
Change of the ecom-ST device
address for Modbus RTU
Define assignment of measured
value - memory address:
1. Address 0x3000
2. Address 0x3001 etc.
Define assignment of measured
value - memory address:
1. Address 0x2000
2. Address 0x2001 etc.
Example
See ecomModbus
See ecomModbus
Standard setting 2
Setting change
Entry after activation
with Enter
Selection with cursor
keys
See ecomModbus
Selection with cursor
keys
Possible measurement
values, see next table
