1.3 Keypad

1
2
3
Connection LED
(only by wireless
1
connection)
Info LED (for
indication of
2
instrument status)
Battery LED (for
indication of
3
charging status)
Function keys
(assignment shown
4
on display)
NOTE
In input mode, the numerical function of the keys is used to enter
figures.
ecom-ST 1.0
4
ESC key
5
(quit/escape menu)
Digital flow indi-
6
cation/flow meter
Enter key (confirm
7
selection)
Cursor control
8
(up/down/right/left)
5
8
7
10
Store key
9
Info key (access to
10
control menu)
ON/OFF key
11
6
9
11
