6.1.2 Time control

CAUTION
Invalid measurement results
Sensor drift phenomena lead to higher inaccuracies.
Use the device only with time control!
The following settings can be made:
Parameter Meaning
Interval time Total time per cycle
Time during which the measured
values are available. At the end of
Measuring
the measuring time, a data record
time
is saved under 0x2000 and
following.
Switching on the automatic mode.
Automatic Operation without time control is
not permitted.

6.1.3 Configuring the Analog outputs (option)

Gas analysis
Adjustments
Control
Remote setup
31 Stat:
2 T.Gas 20.0 400.0 °C
12 CO2 0.00 20.00 %
4 O2 0.00
5 CO 0
6 NO 0.0 100.0 ppm
7 NO2 0.0
28 NOx 0.0 100.0 ppm
34
1. Switch on instrument.
2. Select "Remote setup" with Enter.
3. Select "Analog outputs" with Enter.
4. Select desired value with cursor keys
5. Confirm with Enter.
6. Input 4 mA value via numerical keys.
7. Confirm with Enter.
8. Input 20 mA value via numerical keys.
9. Confirm with Enter.
5.00 %
500 ppm
10.0 ppm
(left/right).
Adjustment change
Entry after activation
with Enter: 10 to 2550
minutes
Entry after activation
with Enter: 5 to 60
minutes
ON / OFF after
activation with Enter
