For example, to enter an 'R', press 7 (labelled PRQS). Each time you
press 7, the display shows a different letter–first 'P', then 'Q', 'R', 'S',
and finally '7.'
The letter appears on the display as shown below.
NAME:R
2. When the letter you want appears on the display, press another
number key labelled with the next letter you want.
If the next letter is printed on the same number button, move the
cursor right by pressing ❿, then press the button.
The blinking cursor moves right and the next letter appears on the
display.
NAME:RP
3. Select additional letters in the same way. When you have finished
entering the letters, press START/ENTER.
KEYPAD CHARACTER ASSIGNMENTS
Key Assigned numbers, letters, or characters
Space
1
A B
2
D E
3
G H
4
J K
5
M N
6
P Q
7
T U
8
W X
9
+ -
0
1
C 2
F 3
I 4
L 5
O 6
R S 7
V 8
Y Z 9
, . ' / # & 0
3.21
Stand-alone Fax
