Autoslide iLock Installation Manual page 24

PROGRAMMING PET OPENING WIDTH (FOR PET APPLICATION ONLY)
To start the pet programming process, flip
5)
DIP switch #3 ON and back OFF.
- The door will immediately open until it
hits a doorstop. Manually brace the door
when it reaches the desired pet opening
width to keep it from opening any further.
Once the programming process is started,
the door will:
1. Slow open fully or until stopped
2. Slow close fully
Once the door remains in the fully closed
position with a solid Orange Mode light, the
pet opening width is programmed.
To test the door, press the button for Pet Sensor
located on the right of the control panel. The
door should open to the partial pet width and
close automatically.
Once the Normal opening width, Stacker opening width, and Pet opening
width (if needed) are programmed, the AutoSlide unit setup process is
complete.
Note: If power is turned off, the motor (locking or non-locking) will completely
disengage for egress and allow manual operation of the door.
Additionally, if power is turned off and back on, all settings are retained.
When power resumes, the door will slowly close until it hits the close jamb or
doorstop. However, the opening widths will not need to be reprogrammed.
