PROGRAMMING FULL OPENING WIDTH
Ensure an open jamb/doorstopper is in
place in the desired max opening
3)
position, so the door doesn't run off
the AutoSlide track.
To start the programming process,
reverse DIP switch #1 from its current
position, then immediately reverse back
DIP switch #1 (flip it back and forth).
- The door will immediately open until it
hits an open jamb or doorstop. If none
exist, manually brace the door when it
reaches the desired opening width to
keep it from opening any further.
Once the programming process has
started, the door will:
1. Slow open fully
2. Slow close fully
3. Fast open partially
4. Slow close fully
Once the door remains in the fully closed
position with a solid Green Mode light, the
full opening width is programmed.
To test the door, press the button for Inside
Sensor located at the top right of the control
panel. The door should open and close
automatically (if the Open Time dial isn't set at
the max position).
