- Page 1 Installation Manual autoslide.com...
-
Page 2: What's In The Box
What’s in the Box • AutoSwing Operator • L Bracket • Extension pinion • Two Touch Buttons • Push/Pull Arm (Out-swing Door) or Slide Arm with Rail and Cover (In-swing Door) • Power Supply • Screw Packet • Backup Battery (Pro Version) •... -
Page 3: Technical Information
1. TECHNICAL INFORMATION 22.56 inch (570 mm) 3.14 inch (80 mm) 2.25 inch (60 mm) Clip On Safety Cover Front View Side View Features Operator Features and Performance The AutoSwing Automatic Door Operator offers a high • Compact slim design standard of performance within a slimline design. - Page 4 Components OPERATOR Motor Microcomputer Controller Output Axis COVER SLIDE ARM - IN-SWING SLIDE ARM COVER PUSH/PULL ARM – OUT-SWING NOTE: AutoSwing comes with either one of the two arms.
-
Page 5: Installation Example
INSTALLATION INSTALLATION EXAMPLE Choose pull arm: Door leaf open toward inside (operator is inside) Choose push arm: Door leaf open toward outside (operator is inside) - Page 6 INSTALLATION INSTALLATION OF THE BASE - PULL ARM/PUSH ARM Using a flat screw driver, clip off the safety cover. Plug the power cable into the back of the AutoSwing.
- Page 7 INSTALLATION INSTALLATION OF THE BASE - SLIDE ARM FOR IN-SWING DOORS Fully close the door. Fix the base on the frame with six countersunk wood screws, use a level throughout this process. Make sure the edge of the base is aligned to the edge of the door. •...
- Page 8 INSTALLATION - SLIDE ARM Remove the cover and endcaps of the rail. Keep the door fully closed. If installing onto right hinged door, rotate the arm full to the left. Slide the rail along the ball of the arm. Hold the rail up to The rail should be flush against the door panel.
- Page 9 INSTALLATION - SLIDE ARM POWERING ON AND INITIALIZING Configure DIP switch settings as desired. Ensure DIP switch Power the system on, if it starts to open the door immediately #1 is flipped OFF. then power the system off and reverse DIP switch #1 then (Towards the front of the controller).
- Page 10 INSTALLATION - PUSH ARM AutoSwing Operator The hinges/pivot point 1. Before beginning, secure door so it does not move during 2. The operator will need to be mounted so the edge of the installation and set up your ladder/stool. AutoSwing aligns over the hinges or pivot position of the door. For an Out-swing Left-Hand Door, the left edge of the Au- toSwing aligns with the hinges/pivot point.
- Page 11 Lock Port. Then connect the ground wire to the #4 hole on the Lock Port. c. Smart Lock: Open the Autoslide app and look in Settings to select the Smart Lock you want to integrate. Follow the instruc- tions in App. You may need an AutoPlus Gateway to complete the integration.
- Page 12 AUTOSWING CONTROLLER SYNC The SYNC button is used to pair the AutoSlide app on your smartphone to the AutoSwing system. Download AutoSlide Pro on the App Store or download AutoSlide for Android. Sensor Learn This button is used to pair wireless sensors to your AutoSwing system, including touch buttons, key FOB remotes, safety sensors, and any other wireless activation device offered by AutoSlide.
- Page 13 Device”, and follow the App instructions. 4- Using your AutoSlide App, click on your AutoSwing door, and go to Door Settings, tap on “Door” in LEARN OPEN WIDTH section to set how wide your door can open. First tap and the door will start opening.
- Page 14 DATA VCC GND GND GND +24V +24V AUTOSWING CONTROLLER MOTOR + PULSE GND QUAD MOTOR - DATA VCC GND GND GND +24V +24V Port 1: To connect Left End Cap Port 2: To connect Samrt Locks MOTOR + PULSE GND QUAD MOTOR - Port 3: To Connect Autoswing Motor...
-
Page 15: Fire Alarm Input
FIRE ALARM SETUP Fire Alarm for swing door: Dip8 for alarm input signal (stacker port): OFF: no reverse input alarm signal (normal open). ON: reverse input alarm signal (normal close, link to 0V). Dip9 for when alarm on, door moving positon: open or close. Dip9 Dip8 (revers input signal) I/p signal from Fire... - Page 16 SENSORS If you are using a wired safety sensor and a pet sensor, you will need a Y connector to allow both to be used. • For the wireless safety sensors, you use a wireless IR sensor. Each side of the door needs a safety sensor. •...
- Page 17 Connect the power cable to the AtuoPlus After configuration, control your doors with the and plug the power adapter into a working Autoslide app. outlet. To test the Autoslide app, open the app, select your device, and press Inside to activate a door opening.
- Page 18 SETUP Color Meaning Reset the AutoPlus Reset your AutoPlus Gateway by gently inserting White (solid) Starting up a paperclip into the pinhole on the back of the unit. This will change the LED status to blue and then back to white. White (fade in and out) Ready to pair The LED will briefly flash amber while the...
- Page 19 SAFETY INSTRUCTIONS This document contains important instructions for installation of i-swing door operators. Review these instructions thoroughly prior to installation, and follow them carefully during installation, commissioning, troubleshooting and maintenance. In case of Dip Switch 7 is ON (Heavy Force), two safety sensors for opening and closed required. ALL LOW ENERGY DOORS Automatic Caution Door Decal •...
-
Page 20: Safety Warnings
SAFETY WARNINGS WARNING An incorrect installation may result in damage to equipment or incorrect equipment operation WARNING Electric shock hazard! By use of control elements, settings, or procedures not documented in this manual! WARNING Work on electrical equipment and 115 Vac wiring installation must be only be performed by qualified personnel! WARNING... - Page 21 SAFETY WARNINGS Main closing edge Opposing closing edge WARNING Crushing hazards at door closing edges! WARNING Hand pinch point and crushing hazards at arm and track!
- Page 22 Detachable Power Supply Cord Marking- “ WARNING : USE ONLY ADAPTOR PROVIDED FOR USE WITH OPERATOR, OTHER ADAPTOR MAY RESULT IN RISK OF FIRE. SEE INSTALLATION INSTRUCTIONS FOR DETAIL” or equivalent. Manufacturer’s Name AUTOSLIDE PTY LTD Trademark AUTOSWING Catalogue number...
- Page 23 FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
- Page 24 To find out more about AUTOSWING, please visit autoslide.com...
