Autoslide iLock Installation Manual page 15

TRACK CUTTING
2)
a) Join the tracks together
using the grooves at the
ends.
b) Fully close the door into the jamb.
Measure the exposed width of the
sliding panel (from the back edge
of the sliding panel to the start of
the jamb). Use a hacksaw to
cut the tracks to match this width.
Note: If the location of the cut is not near a
mounting hole on the track, you can either drill a
new hole into the track or use one of the optional
track endcaps for support. Four additional teeth
may need to be cut from the track for each
endcap. If using track endcaps, ensure the motor
wheel does not hit an endcap (whether fully open
or fully closed) once the tracks are mounted.
Note: If the total track length is shorter than the
sliding panel width, the AutoSlide will still be able
to automatically open the door partially. In this
case, a door stopper should be installed to
prevent the sliding panel from opening too far and
running off the AutoSlide track.
SLIDING PANEL
(fully closed into jamb)
