INSTALLATION PROCEDURES
Connection
one-to-one
HDMI IN
Video Source
Follow the standard of IEEE-568B. It is recommended to select a
network cable with less loss and crosstalk.
1-Orange/white
2-Orange
3-Green/white
4-Blue
5-Blue/white
6-Green
7-Brown/white
8-Brown
WWW.TECHLY.COM
HDMI Display
Network Cable
TX
Speaker
HDMI Display
HDMI EXTENDER
BY CAT. 6
RX
HDMI OUT
ARC
