HDMI EXTENDER
BY CAT. 6
• Do not unplug the deive when it is in using, keep distance from
flammable and explosive devices.
• Power supply: DC 5V/2A, usage only the supplied power unit, do
not use the power supply if it is damaged. Make sure specification
matched if using 3rd party adapters.
• Static electricity will cause damage of the device, please do ESD
protection when using the device.
FEATURES
This HDMI Extender includes a transmitter unit and a receiver unit, allows
HDMI signal to be transmitted up to 70 meters at 4K resolution using a
CAT6/6A/7 network cable. It is perfect for outdoor advertising, video clips,
monitor system, home entertainment, and conference, etc.

SPECIFICATIONS

• Zero latency.
• 4K@60Hz HDMI signal can be transmitted 70 meters through a
CAT6/6A/7 network cable.
• The receiver can extract the digital audio from the transmitter
through the S/PDIF port.
• Supports audio formats (Dolby TrueHD 7.1CH/Dolby Digital
5.1CH).
• Supports HDR(YUV4:4:4), EDID passback.
• Transmitter support one HDMI loop-out.
• Support bi-directional IR passback function (20~60KHz).
• Lightning Protection, Surge Protection, ESD Protection.

PACKAGE CONTENTS

Make sure your package includes the following items:
• Transmitter Unit *1
• Receiver Unit *1
• Power supply DC5V/2A *2
• IR blaster extension cable *1
• IR receiver extension cable *1
• Mounting brackets *8
• Screw *18
• User Manual

INSTALLATION REQUIREMENTS

• HDMI source device like computer graphic cards, DVD, PS3, HD
monitoring equipment etc.
• HDMI display device like SDTV, HDTV, projector with HDMI port.
• UTP/STP CAT6/CAT6A/CAT7 cable. Follow standard IEEE-568B.
It is recommended to select a network cable with less loss and
crosstalk.
