Uniq 150
It is possible to set hinge tilt after its removing and setting marked screws (stoppers) and actually
change Uniq 150 execution. It is necessary to adjust lock hinge and change direct cuff to angled cuff when
change execution from standard to N3 or T1.
Table 2.9.1. – Tilt setting
Execution N1 N2 N3
Recommended
table/wall table/wall table/wall
way of placing
–15°/15° 0°/30° 78°/107°
Angle
(75°/105°) (90°/120°) (–12°/17°)
Stopper position B-B A-A B-B
Lock hinge P: Y-Y P: X-X U: Z-Z
Cuff
P P U
Direct (P)/Angled (U)
Stand
L3 L3 L2
Leg (Lx)/Tube Holder (TH)
L1 – cables gap direction: forward; leg jambs direction: forward
L2 – cables gap direction: forward; leg jambs direction: backward
L3 – cables gap direction: backward; leg jambs direction: outward
Figure 2.9.3. – Hinge structure and tilt setting
24
Service manual
N4 N5 N6 T1 T2
table/wall table/wall table ceiling/floor ceiling/floor
9°/39° 24°/54° 90°/117° –25°/5° 87°/117°
(99°/129°) (114°/144°) (0°/27°) (155°/185°) (–93°/–63°)
B-B A-A A-A B-B B-B
P: Y-Y P: X-X U: V-V U: Z-Z P: Y-Y
P P U U P
L1 L1 L3 TH TH
Elcom, spoločnosť s ručením obmedzeným, Prešov
Service manual
T3
B
ceiling/floor
A
102°/132°
Y
X
(–78°/–48°)
A-A
P: X-X
P
TH
N1
N3

2.10. MS reader installation

1. It is necessary to adjust these components according to figure:
a. Rear cover of Uniq 150 – drill a hole
b. Side profile – cutting according to reader holder
c. Right stripe of front cover – cutting (only Nx)
d. Left stripe of front cover – cutting (only Tx)
2. Unscrew particular screws according to execution (Nx/Tx).
3. Cut out cable connector of MS reader and insulate the cable ends.
4. Reader cable put through the side profile (ø4), then drilled hole of rear cover and finish adjustment of MS
reader cable:
Elcom, spoločnosť s ručením obmedzeným, Prešov
Hinge
B
A
B
Z
V
P
Lock hinge
Examples of positions:
N2
T1
N6
N4
N5
Uniq 150
B
A
A
U
T2
T3
25
