DPS Telecom NetGuardian 420 Hardware User Manual page 107

456-463 DX2 Analog2 1-8
464-471 DX2 Analog3 1-8
472-479 DX2 Analog4 1-8
480-487 DX2 Analog5 1-8
488-495 DX2 Analog6 1-8
496-503 DX2 Analog7 1-8
504-511 DX2 Analog8 1-8
512-519 DX3 Analog1 1-8
520-527 DX3 Analog2 1-8
528-535 DX3 Analog3 1-8
536-543 DX3 Analog4 1-8
544-551 DX3 Analog5 1-8
552-559 DX3 Analog6 1-8
560-567 DX3 Analog7 1-8
568-575 DX3 Analog8 1-8
Binary Output Status Points and Control Relay Output Blocks
Binary Output Status Points
Static Variation: Obj 10 Var 02 - Binary Output Status
Request function codes supported: 5 (direct operate), 6 (direct operate, no ack)
Supported relay output: Latch on, Latch off.
Point ID Description
0 Control 1
1 Control 2
2 Control 3
3 Control 4
4 DX 1 Control 1
5 DX 1 Control 2
6 DX 1 Control 3
7 DX 1 Control 4
8 DX 1 Control 5
9 DX 1 Control 6
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Class
0
0
0
0
0
0
0
0
0
0
101
