Be sure to read before handling. Refer to pages 14-21-3 to 14-21-4 for Safety Instructions and Common
Precautions.
Caution
Connect the cable to the connector on the body with
the wiring arranged as shown below. Proceed
carefully, as incorrect wiring can cause damage.
Further, use DC power with sufficient capacity and a
low ripple.
Brown
Blue
White
Black
Note)
Body
Current Signal Type
Voltage Signal Type
1 Brown
2 White
3 Blue
4 Black
Note) A right angle type cable is also available. The entry
direction for the right angle type connector is to the left
(SUP port side). Never rotate it, since it's not designed to
turn.
Wiring diagram
Current signal type
Vs
A
Vs : Power supply 24 VDC
A : Input signal
Preset input type
S1
Vs
S2
Vs : Power supply 24 VDC
One of the preset pressures P1 through P4 is selected by the
ON/OFF combination of S1 and S2.
S1
S2
Preset pressure
∗ For safety reasons, it is recommended that one of the preset pressures be
set to 0 MPa.
14-8-34
Downloaded from Elcodis.com electronic components distributor
3: (Blue) 1: (Brown)
4: (Black)
RESET
Preset Input Type
Power supply 1 Brown Power supply
Input signal 2 White Input signal 1
GND (COMMON) 3 Blue GND (COMMON)
Monitor output 4 Black Input signal 2
Voltage signal type
Brown
Blue
Vs
White
Black
Vin
Vs : Power supply 24 VDC
12 to 15 VDC
4 to 20 mADC Vin: Input signal
0 to 20 mADC
Brown
Blue
White
Black
12 to 15 VDC
OFF ON OFF ON
OFF OFF ON ON
P1 P2 P3 P4
Precautions
Wiring
Monitor output wiring diagram
2: (White)
Brown
Blue
White
Black
12 to 15 VDC
0 to 5 VDC
0 to 10 VDC
∗ When 30 mADC or more is applied, detecting device for overcurrent
starts activating and then emits an error signal. (Error number "5")
Analog output: Voltage type
Brown
Blue
White
Monitor output voltage
Black
Switch output: NPN type
Brown
Blue
Load ∗
White
Black
Switch output: PNP type
Brown
Blue
White
Load ∗
Black
Analog output: Current type
Brown
Blue
Monitor output current
White
Black
