Installation and Maintenance Manual
Series ITV2000 Electro-Pneumatic Regulator
For future reference, please keep this manual in a safe place
This manual should be read in conjunction with the current catologue.
Safety Instructions 2. Only trained personnel should operate pneumatically
operated machinery and equipment.
These safety instructions are intended to prevent a hazardous situa-
Compressed air can be dangerous if an operator is unfamiliar with
tion and/or equipment damage.These instructions indicate the level it. Assembly, handling or repair of pneumatic systems should be
of potential hazard by label of "Caution", "Warning" or "Danger". performed by trained and experienced operators.
To ensure safety, be sure to observe ISO4414 (Note1) , JIS B 8370 (Note2)
and other safety practices. 3. Do not service machinery/equipment or attempt to
Note 1: ISO 4414: Pneumatic fluid power – Recommendations for the remove component until safety is confirmed.
application of equipment to transmission and control systems. 1) Inspection and maintenance of machinery/equipment should
Note 2: JIS B 8370: Pneumatic system axiom. only be performed after confirmation of safe locked-out
control positions.
CAUTION : 2) When equipment is to be removed, confirm the safety process
Operator error could result in injury or
as mentioned above. Switch off air and electrical supplies and
equipment damage.
exhaust all residual compressed air in the system.
3) Before machinery/equipment is re-started, ensure all safety
WARNING:
Operator error could result in serious
measures to prevent sudden movement of cylinders etc.
injury or loss of life.
(Bleed air into the system gradually to create back-pressure,
i.e. incorporate a soft-start valve).
DANGER :
In extreme conditions, there is a
possible result of serious injury or loss of life. 4. Contact SMC if the product is to be used in any of the
following conditions:
1) Conditions and environments beyond the given specifica-
WARNING tions, or if product is used outdoors.
2) Installations in conjunction with atomic energy, railway, air
1. The compatibility of pneumatic equipment is the respon- navigation, vehicles, medical equipment, food and beverage,
sibility of the person who designs the pneumatic system recreation equipment, emergency stop circuits, press
or decides its specifications. applications, or safety equipment.
Since the products specified here are used in various operating 3) An application which has the possibility of having negative
conditions, their compatibility for the specific pneumatic system effects on people, property, or animals, requiring special
must be based on specifications or after analysis and/or tests to safety analysis.
meet your specific requirements.
CAUTION
Ensure that the air supply system is filtered to 5 micron.
Specifications
Model ITV201 ITV203
Max. Supply Pressure 0.2MPa (2.0 kgf/cm 2 )
0.005 to 0.1MPa 0.005 to 0.5MPa
Setting Pressure Range
(0.05 to 1.0 kgf/cm 2 ) (0.05 to 5.1 kgf/cm
Supply Voltage DC24V±10%, DC12~15V
Supply Voltage DC24V type: 0.12A or less
Current Consumption
Supply Voltage DC12V type: 0.18A or less
(Note 1)
4-20mADC, 0-20mADC
Current type
Input Signal
Voltage type 0-5VDC, 0-10VDC
Current type 250Ω or less
Input Impedance
Voltage type Approximately 6.5kΩ
Analog Output 1-5VDC (Load impedance: 1kΩ or less)
(Note 2)
NPN Open connector output: 30V, 30mA
Output Signal Switch Output
PNP Open connector output: 30V, 30mA
Linearity ±1% or less (Full Span)
Hysteresis 0.5% or less (Full Span)
Repeatability ±0.5% or less (Full Span)
Sensitivity 0.2% or less (Full Span)
Temperature characteristics ±0.12% or less (Full Span) /˚C
Output Pressure Accuracy ±3% (Full Span)
display (3 digit) Minimum Unit MPa: 0.01, kgf/cm 2 : 0.01, bar: 0.01, PSI: 0.1
0 to 50˚C
Ambient and fluid temperature
(Without condensation)
(Note 1) Two wire control, 4 to 20mADC and 0 to 20mADC are not available. Supply voltage of 12VDC or 24 VDC is required.
(Note 2) Please make a selection of either Analog output or Switch output. Also select either NPN output or PNP output when Switch
output is selected.
(Note 3) 1PSI is the minimum unit on ITV205
Fig 3
Operation Principal (Fig 4)
When the input signal increases, the supply solenoid valve turns on and the exhaust solenoid valve
the pilot valve through the supply solenoid valve. The pilot valve will open the main valve allowing partial supply pressure to pass to the out
port.
The pressure sensor will provide output pressure feedback to the control circuit . The control circuit will balance the input signal and out-
put pressure to ensure that the output pressure remains proportional to the input signal.
Set-key
Down
Key
Air supply port
Fig 1
Symbol
ITV205
1.0MPa (10.2 kgf/cm 2 )
0.005 to 0.9MPa
2 ) (0.05 to 9.2 kgf/cm 2 )
Fig 2
Power supply
Input signal
Supply solenoid
valve
(Note 3) kPa: 1
SUP
Pilot valve
Fig 4
turns off. Supply pressure is passed to
Block line chart
Electrical connector
+
Up-key
Input signal
Control
circuit
LED display
Fig 5
CAUTION
Wiring
Air outlet port
Connect the cable to the connector on the main unit as shown in the
following diagram. Take precautions as incorrect wiring will damage
the unit. Use a DC power supply capable of supplying the necessary
power requirements with minimal ripple.
1 Brown Power supply
2 White Input signal
Brown
Blue
3 Blue GND (COMMON)
White
4 Black Monitor output
Black
Note)
Gauge port
3: (Blue)
Main unit
4: (Black)
Note: The right angle type connector extends to the
left side (over the supply port side).
Wiring diagram
Current signal type
Voltage signal type
Brown
Blue
White
Black
Pressure
indicator Vs: Power supply 24VDC Vs: Power supply 24VDC
12VDC
Control
A: Input Signal 4 to 20mADC Vin: Input Signal 0 to 5VDC
circuit
0 to 20mADC
Fig 6
Exhaust
solenoid valve
Pressure sensor
OUT
Straight Type Connector Right Angle Type Connector
Fig 7
Supply pressure
Output
Supply solenoid
pressure
valve
Pilot valve
Exhaust
solenoid valve
Pressure sensor
Setting the Regulator
CAUTION
As soon as the 'set' key is operated minimum/maximum pressure will
be present at the outlet port.
CAUTION
As soon as primary pressure is applied to the regulator minimum
pressure will be present at the outlet port.
• Release 'lock key' (Fig 1) as explained in section - 'Function of
key-lock'.
• To set minimum pressure (display shows F-1 Fig 1) use up/down
1: (Brown)
keys (Fig 1) to set minimum pressure, press 'set' key (Fig 1) to
'lock' setting.
2: (White)
• To set maximum pressure (display shows F-2 Fig 1) use up/down
keys (Fig 1) to set maximum pressure, press 'set' key (Fig 1) to
'lock' setting.
Switch output PNP/NPN
• To set switch output 1 (display shows P-1 Fig 1) use up/down keys
to set switch output, press 'set' key (Fig 1) to 'lock' setting.
• To set switch output 2 (display shows P-2 Fig 1) use up/down keys
to set switch output.
Note 1: If the above sequence of events has been followed
correctly, the settings will complete automatically.
Note 2: If only setting minimum pressure, when pressure is
'set', pressing the set button once more will 'skip' to
Brown
the next step.
Blue
Function of Key-Lock
White
Black
With input signal applied
Loc unL
a b
Push 'down' key (Fig 1) for longer than 2 seconds. Display (a)
12VDC flashes 'loc'.
1. Push 'set' key (Fig 1) lock automatically releases.
0 to 10VDC Note: Push 'down' key (Fig 1) again to cancel operation.
2. Key Lock Release
1. Push down on 'un-lock' (Fig 1) key for longer than 2 seconds.
2. Key-lock will release.
Note: To cancel push 'lock' key (Fig 1).
3. To Lock
1. Push down on 'up' (Fig 1) for longer than 2 seconds.
2. Led will flash 'unL' (un-lock).
3. Push 'set' key (Fig 1) to lock.
Note: To cancel push 'down' key (Fig 1).
Function of the 'Error' Display
If an abnormality is detected by the ITV2000, the LED display (Fig 1)
will show 'Er' followed by a code number. Isolate the power supply
and ascertain and solve the problem. Re-instate power supply after
correcting the fault.
Error codes are as follows:
No Content Display
1 Input Signal Outside Spec.
2 EEProm Reading/Writing Error
3 Memory Reading/Writing Error
4 Solenoid Valve Fault
5 Switch Output Over-Current
Reset Function
Push up and down keys (Fig 1) together for longer than 3 seconds.
Display (Fig 1) shows 'RES'. Release keys, minimum, maximum
pressures, switch outputs P1 and P2 are reset to start condition.
CAUTION
1. If the electrical supply fails, settings are 'held' for a short period.
2. If the air pressure fails with power 'on' the solenoid will 'flutter'.
Turn off the power.
3. If the monitor output function is not used, ensure that the wire is
totally insulated.
PNP Circuit
Brown
White
Sensor
Black
Load
Blue
Note: If the supply exceeds 30mA the sensor will output
to the LED display (Fig 1) and show 'Er 5'.
CAUTIONS
1. This product (ITV2000) is pre-set at the factory and must not be
dismantled by the user. Contact your local SMC office for advice.
2. Ensure, when installing this product, that it is kept clear of power
lines to avoid noise interference.
3. Ensure that load surge protection is fitted when inductive loads
are present (i.e. solenoid, relay etc.).
4. Ensure precautions are in place if the product is used in a 'free
flow output' condition. All will continue to flow continuously.
5. Do not use a lubricator on the input side of this product. If
lubrication is necessary, place the lubricator on the 'output' side.
6. Ensure all air is exhausted from the product before maintenance.
