Dimensions
ITV30
Flat bracket
M5 x 0.8
Solenoid
valve EXH
SUP (1)
L-bracket
(10)
(7)
Downloaded from Elcodis.com electronic components distributor
Electro-pneumatic Regulator
52
4 x ø7
40
Mounting hole
RESET
SET
UNLOCK LOCK
E
SMC REGULATOR
P
ITV3000
G
SUP (2)
Flat bracket
P3020114
(Optional)
G
L-bracket
30
INI-398-0-6
36
(Optional)
ITV1000/2000/3000
Series
Note) Do not attempt to rotate, as the cable connector does not turn.
Cable connector (4-wire)
Right angle type
SMC REGULATOR
ITV3000
12.5
Solenoid valve
EXH
2 OUT
36
2 x Rc1/4, 3/8, 1/2
Port size
2 OUT
36
2 x Rc1/4, 3/8, 1/2
SUP port, OUT port
Cable connector (4-wire)
Straight type
SMC REGULATOR
ITV3000
M12 x 1
Cable connection threads
Rc1/2
Exhaust port
EXH (3)
4 x M5 x 0.8 thread depth 6 mm through
Mounting hole
2.3
45
