Levelflex FMP53
Endress+Hauser
Accessory Description
Mounting bracket for the
electronics housing
A
B
Accessory Description
Weld-in adpater
M24 D65
With M24x1.5 thread for flush-mounted sensors.
Material: 1.4435 (AISI 316L)
Weight: 0.22 kg (0.48 lbs)
Order No.
• Standard version: 71041381
• with 3.1 material certificate: 71041383
For details see Operating Instructions BA361F.
Accessory Description
Protective cover
With the protective cover the probe can be locked with dismantled electronics.
Order no.: 71041379
For details refer to Operating Instructions BA362F.
A
122 (4.8)
158 (6.2)
Wall mounting
Pipe mounting
For the "Sensor remote" device version (see feature 060 of the product structure),
the mounting bracket is part of the delivery. If required, it can also be ordered as an
accessory (order code 71102216).
Ø 65 (2.56)
B
140 (5.5)
175 (6.9)
Ø 42 ... 60
(1-1/4 ... 2)
mm (inch)
Accessories
mm (inch)
A0014793
A0013588
A0013589
