12
Jumper installed for current
Current
4 to 20 mA
250 Ohm
Current Source
Shunt
Transducer
Jumper removed for voltag e
Voltage
Voltage Source
Transducer
5. Slide the top cover of the case back into position and replace the screws.
6. Reconnect and power up the Cell16 .
5.6.2

Analog Step Sizes

Input Voltage Range
5.6.3

D-Wire External Sensors

The ports on your Cell16 labeled Digital Sensors support up to 16 D-Wire sensors. Your Cell16 powers and
communicates with your D-Wire sensors via simple RJ-11 connections. You can chain your 16 sensors to the D-
Wire port on the Cell16 .
The max cable length depends on the number of sensors daisy chained together. The cable lengths and
corresponding number of sensors can be seen in the table below.
Analog
Channel
Input
Unjumpered/Open Position:
Analog
Channel Voltage Operation (default)
Input
Jumper settings for analog alarms inputs.
Analog Step Sizes
Resolution (Step Size)
0-5 V
5-14 V
14-30 V
30-70 V
70-90 V
Analog step sizes
Maximum Cable Lengths
Jumpered/Closed Position:
Current Operation
.0015 V
.0038 V
.0081 V
.0182 V
.0231 V
Jumper Analog
J20
J21
J22
J23
Accuracy
+/- .05V
+/- .14V
+/- .30V
+/- .70V
+/- .90V
ANA 1
ANA 2
ANA 3
ANA 4
