CX 9150, CX 9330, CX 9753, CX 7110 L, CX 7310 L, CX 9156, CX 9301, CX 9356, and CX 9701
* The image is a general overview and is not necessarily the same as the product you receive.
* Features and other attributes are depending on the type of products
1. Control Panel
2. Cassette Aluminum Filter
3. Cassette Aluminum Filter Handle
4. Lamp
5. Main Chimney
6. Upper Connector Chimney
7. Circulation Hole
CX 7712
* The image is a general overview and is not necessarily the same as the product you receive.
* Features and other attributes are depending on the type of products
Part 2: Name of Parts
5
