Plug the activated carbon filter into the unit and turn it in clockwise direction. Repeat the same on the other side
Warning:
Carbon filters cannot be wash or recycle. Maximum use of carbon filter is 120 hours of use and
must be replaced afterwards. Carbon filters should not be exposed to heat
CX 9157, CX 9177, CX 9777
IMPORTANT: Installation must be carried out by our registered contractors
Installation Height
Minimum height from the hob surface to the underside of range hood:
-
300 mm for electric hob
-
350 mm for gas hob
*If the instruction for the gas hob installation specified a greater distance, this has to be taken into account
NOTE: Any installation above 700mm will compromise the performance of this range hood. The total height of the
hood is 660 mm. In order to disassemble the protective cover smoothly, the distance between the top end of the hood
and the ceiling is at least 20 cm, and the distance between the two sides of the hood and the kitchen cabinet is 10 mm.
NOTE: Any installation above 700mm will compromise the performance of this range hood. The total height of the
hood is 660 mm. In order to disassemble the protective cover smoothly, the distance between the top end of the hood
and the ceiling is at least 20 cm, and the distance between the two sides of the hood and the kitchen cabinet is 10 mm.
Note:
Make sure the filter is securely locked. Otherwise, it would
loosen and cause dangerous.
When activated carbon filter attached, the suction power will
be lower.
Carbon filters are installed at the rear of the grill and had to
be replaced after three months.
13
