Figure 12 Mac Address Definition For Device Profile Instance - SpectraLink IP-DECT 200 Configuration Manual

Alternatively, use the instructions detailed in the following sub-sections to manually alter
files in the existing device profile types and device profile instances to switch the file
authentication mode.
Caution: Altering the authentication mode from "username/password" to "MAC address in client
certificate" for a given device profile type will affect all existing device profile instances on the
BroadWorks system. Prepare the authentication mode switch by collecting all MAC addresses
of the existing Spectralink IP DECT Servers and follow instructions below in the specified order.
5.2.7.1 Create or Modify Device Profile Instance using MAC Address from Client Certificate
When MAC address authentication is chosen as the file authentication mode, every single
IP DECT Server's MAC address must be added to the corresponding device profile on
BroadWorks. The device MAC address is to be configured for the device profile as shown
in the following figure. Further, select or update the Authentication method of Use Custom
Credentials instead of Use Identity/Device Profile Type Credentials. If altering the
authentication mode, repeat the steps to modify all existing device profiles on the
BroadWorks system.

Figure 12 MAC Address Definition for Device Profile Instance

5.2.7.2 Update Device Management Authentication Mode on the Device Profile Type
Instructions in this section are only applicable to updating BroadWorks systems with
existing Spectralink IP DECT Server device profile types. Perform the changes as shown
on the device profile type to be updated with MAC address authentication using Client
Certificate.
Parameter
BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES
© 2019 BROADSOFT INC.
Value Description
20-BD5445-00
PAGE 41 OF 49
