Configure Service Settings; Subscriber Level Configuration; Sip Advanced Feature Configuration; Shared Call Appearance Configuration - SpectraLink IP-DECT 200 Configuration Manual

XML File
sip.dnsmethod = dnssrv
4.2.3

Configure Service Settings

XML File Tag
feature_codes.enable = true
4.3

Subscriber Level Configuration

This section identifies the device-specific parameters, including registration and
authentication. These settings must be unique across devices to be matched with the
settings for a BroadWorks SIP trunk or subscriber. SIP Registration requires that a unique
address of record (AoR) is provisioned on BroadWorks and the device.
XML file tag
user.username = 123456
user.authuser = SpectralinkUser1
user.authpassword = Spectralink01
user.displayname = User 1
user.standbytext = 123456 User 1
4.4

SIP Advanced Feature Configuration

This section provides configuration instructions for advanced SIP features supported by
the phone including but not limited to Shared Call Appearance, Busy Lamp Field, Feature
Key Synchronization, Call Center, Emergency Call, Advice of Charge, Call Recording, and
Security Classification.
4.4.1

Shared Call Appearance Configuration

Not Supported.
BROADSOFT PARTNER CONFIGURATION GUIDE – SPECTRALINK IP-DECT SERVER SERIES
© 2019 BROADSOFT INC.
Description
Set the DNS method used to resolve the SIP
server.
Values:
"arecord": Use DNS A records only.
"dnssrv": Use DNS SRV records and A records.
Default: arecord.
Recommended setting for BroadWorks: dnssrv.
Description
To activate the call forward feature, the setting
needs to be enabled. On Handset activated via
feature code: *21*[forwarding number]#.
Disabled on handset via #21#.
Description
The register user ID must correspond with the
line/port setting on BroadWorks.
If the Authentication service is configured on
BroadWorks, these parameters must be
configured to match the BroadWorks settings.
Note that the password can be saved as hashed
value as well.
The name to be displayed (caller ID) at other SIP
devices, for example, User 1 in User
1<1234566@somecompany.com.
Configure the text to be displayed on the device.
20-BD5445-00
PAGE 21 OF 49
