7 Electrical connection
7.1

Connection conditions

7.1.1 Terminal assignment
Terminal assignment 4-wire: 4-20 mA HART (90 to 253 V
 9 Terminal assignment 4-wire: 4-20 mA HART (90 to 253 V
1 Connection 4-20 mA HART (active): terminals 3 and 4
2 Connection supply voltage: terminals 1 and 2
3 Terminal for cable screen
32
2
1
Micropilot FMR50 FOUNDATION Fieldbus
)
AC
3
)
AC
A0036519
