Micropilot FMR50 FOUNDATION Fieldbus
Step Block
1 SETUP (TRDSUP)
2 SETUP (TRDSUP)
3 SETUP (TRDSUP)
4 SETUP (TRDSUP)
5 SETUP (TRDSUP)
6 SETUP (TRDSUP)
7 SETUP (TRDSUP)
8 SETUP (TRDSUP)
9 SETUP (TRDSUP)
10 SETUP (TRDSUP)
1) only available for "Tank type" = "Bypass/pipe"
Endress+Hauser
Parameter
Distance unit
(distance_unit)
Tank type (tank_type)
Tube diameter
1)
(tube_diameter)
Medium group
(medium_group)
Empty calibration
(empty_calibration)
Full calibration
(full_calibration)
Level (level)
Distance
(filtered_dist_val)
Signal quality
(signal_quality)
Confirm distance
(confirm_distance)
Commissioning (block-based operation)
Action
Select distance unit.
Selection:
• 1010: m
• 1013: mm
• 1018: ft
• 1019: in
Select tank type.
Selection:
• 1271: Process vessel with agitator
• 1272: Process vessel standard
• 1273: Storage vessel
• 1274: Wave guide antenna
• 1279: Sphere
• 32816: Bypass / pipe
• 33013: Open channel
• 33094: Stilling well
Enter the diameter of the bypass or stilling well.
Select medium group.
Selection:
• 316: water based (DC>4)
• 256: other (DC≥ 1.9)
Enter the distance E between the reference point R
and the minimum level (0%).
Enter distance F between the minimum (0%) and
maximum (100%) level.
Displays the measured level L.
Displays the distance D between the reference
point R and the level L.
Displays the signal quality of the level echo.
Compare the displayed distance to the real distance
in order to start the recording of the mapping
curve.
Selection:
• 179: Manual map
• 32847: Factory map
• 32859: Distance ok
• 32860: Distance too big
• 32861: Distance too small
• 32862: Distance unknown
• 33100: Tank empty
