Commissioning (block-based operation)
4. If necessary, assign a description to the block by means of the Tag Description/
TAG_DESC parameter.
5. If necessary, change other parameters as per the requirements.
11.1.3 Configuring the Transducer Blocks
The measurement and the display module are configured using the Transducer Blocks. The
general procedure is the same for all Transducer Blocks:
1. If necessary, change the block name.
2. Set the block mode to OOS by means of the Block Mode/MODE_BLK parameter,
TARGET element.
3. Configure the level measurement →  60.
4. Set the block mode to Auto by means of the Block Mode/MODE_BLK parameter,
TARGET element.
The block mode must be set to Auto for the measuring device to function correctly.
11.1.4 Configuring the Analog Input Blocks
The device has 2 permanently instanced Analog Input Blocks that can be assigned as required
to the various process variables. If required, up to 5 Analog Input Blocks can be instanced
through the FOUNDATION Fieldbus configuration tool.
Analog Input Block
AI 1
AI 2
1. If necessary, change the block name.
2. Set the block mode to OOS by means of the Block Mode/MODE_BLK parameter,
TARGET element.
3. Use the Channel/CHANNEL parameter to select the process variable which should be
used as the input value for the Analog Input Block.
4. Use the Transducer Scale/XD_SCALE parameter to select the desired unit and the
block input range for the process variable →  57. Make sure that the unit selected
suits the process variable selected. If the process variable does not suit the unit, the
Block Error/BLOCK_ERR parameter reports Block Configuration Error and the block
mode cannot be set to Auto.
56
Default settings
CHANNEL
32949: Level linearized
32856: Distance
