Directed Directechs DS4+ Installation Manual page 17

Type 3
Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 18 for important information on this installation.
(+) Accessory:
Keyless Access Control Unit
pin 16
(Gray conn. behind instrument cluster)
(+) Ignition: pin 17
18 17 16 15
(+) 12V: pin 18
36 35 34
Ignition: pin 34
Cut
(White conn. at headlight switch)
17
Keyless Access
Control Unit
(Gray conn. behind
instrument cluster)
14 13 1 2 11 10 9 8 7 6 5 4 3 2 1
33 32 31 30 29 28 27 26 25 24 23 22 21 20 19
(+) Start:
(-) PTS:
pin 32
pin 11
(-) Parking Lights:
pin 8
Headlight Switch
6 5 4 3 2 1
8
12 11 10 9 7
B-CAN High: pin 1
10 9 8 7 6 5 4 3 2 1
B-CAN Low:
20 19 18 17 16 15 14 13 12 11
pin 11
Immo. F-CAN F-CAN
Data: High: Low:
pin 5 pin 2 pin 12
(-) Push-to-Start Output: Lt. Green/Black: 1
(-) Parking Lights Output: Lt. Blue/Black: 10
Hood Pin
Siren
Ignition Interrupt (vehicle side): Blue/White: 1
HS CAN Low 1: Tan: 1
HS CAN High 1: Tan/Black: 2
FT CAN Low 2: Orange/Brown: 3
FT CAN High 2: Orange/Green: 4
Immobilizer Data: Yellow/Black: 8
(+) Accessory Output: White: 7
(+) Starter Output: Violet/Black: 8
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
Ignition Interrupt (conn. side): Blue: 3
(+) 12V : Red: 6 & 12
(+) 12V Input: Lt. Green/Red: 7
(+) Ignition Output: Lt. Green: 8
(-) Ground: Black: 10
It is important to check that the
fuses are positioned correctly.
DS4+ DS4
Proper Fuse
Positioning
DS4
Slide
DS4+
to open
DS4+ HONDA7
