Directed Directechs DS4+ Installation Manual page 30

Type 7
Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 31 for important information on this installation.
(under drivers dash)
35
Immo.
Data:
Lt. Green,
pin 35
6
(+) Starter:
Yellow, pin 6
30
OBDII Diagnostic Conn.
F-CAN High: White, pin 6
1 8
9 16
F-CAN Low:
Red, pin 14
BCM
(-) Parking
Lights:
Gray,
pin 11
11
27
(+) 12V:
B-CAN
White,
High:
pin 27
Pink,
pin 20
20
21
B-CAN
Low:
Blue,
pin 21
2 9
32
Ignition: (+) Acc.: (-) PTS:
Gray, Gray, Black,
pin 2 pin 32 pin 9
Cut
HS CAN Low 1: Tan: 1
HS CAN High 1: Tan/Black: 2
FT CAN Low 2: Orange/Brown: 3
FT CAN High 2: Orange/Green: 4
Immobilizer Data: Yellow/Black: 8
(-) Push-To-Start: Green/Black: 1
(+) Starter Output: Violet/Black: 8
(-) Parking Lights Output: Lt. Blue/Black: 10
(+) Siren Output: Brown/Red: 11
Hood Pin
Siren (-) Hood Input: Gray: 21
(+) Accessory Output: White: 5&11
(+) 12V: Red: 6&12
(+) 12V Input: Lt. Green/Red: 7
Ignition Interr. (veh. side): Lt. Green: 8
Ignition Interr. (conn. side): Lt. Green/White: 9
(-) Ground: Black: 10
DS4+ DS4
Proper Fuse
Positioning
DS4
Slide
DS4+
to open
It is important to check that the
fuses are positioned correctly.
DS4+ HONDA7
