eçï=íç=rëÉ=qÜáë=dìáÇÉ
Following are important tips for streamlining your use of this User's Guide in its electronic
"PDF" form.
k~îáÖ~íáåÖ
Use Acrobat Reader's "bookmarks" to navigate to the desired location. All chapter files
have the same bookmark structure for instant navigation to any section. Please note:
•
•
•
•
q~ÄäÉ=çÑ=`çåíÉåíë=~åÇ=fåÇÉñ
Use the Table of Contents bookmarks to navigate a desired topic. Click any item to
instantly jump to that section of the guide. You can also use the Index to jump to specific
topics within a chapter. Each page number in the Index is a hyperlink.
`çåîÉåíáçåë=
The following conventions are used throughout this guide:
•
•
•
•
MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User's Guide
Extensive hyperlinks are provided within the chapters.
Use Acrobat's "Go to Previous View" and "Return to Next View" buttons to trace
your complete navigational path.
Use the "Previous Page" and "Next Page" buttons to go to the previous or next
page within a file.
Use Acrobat's extensive search capabilities, such as the "Find" tool and "Search
Index" tool to perform comprehensive searches as required.
The symbol denotes an operations procedure.
The symbol denotes an example.
Entries written in bold-face capital letters denote physical buttons or chassis
connectors.
SEL
Press to ...
When two buttons together are required for an operation or function, the plus (+)
sign is used between the buttons. This procedure requires that you hold down the
first button, then press the second.
SHIFT + 1/9
Press
How to Use This Guide
to ...
