Extreme Networks ExtremeWireless AP302W Installation Manual page 11

AP302W Overview
Rear ports:
◦
One Ethernet (ETH) port with Power over Ethernet (PoE) in
◦ One pass through port
Bottom ports or user access ports:
◦
Two ETH ports
◦
One ETH port with power-sourcing-equipment (PSE)
◦
One pass through port
•
One LED. The LED will be on during reset
•
One software reset button
•
One Kensington lock
•
One USB 2.0 type A connector, supports up to 2.5W
•
Power: PoE 802.3at and 802.3af (see power table for details)
•
Antennas:
◦ Three internal omni-directional 2.4G/5G dual-band antennas
◦ One internal omni-directional 5G antenna
•
Temperature
◦ Operating temperature: 0 °C to +40 °C (+32 °F to +104 °F)
◦ Non-operating temperature: −40 °C to +70 °C (−40 °F to +158 °F)
•
Enclosure: plastic
ExtremeWireless™ Access Point AP302W
AP302W Features
11
