Circontrol Post eVolve Series Installation Manual page 20

Post eVolve Series Installation Manual
5
DATA GENERAL SPECIFICATIONS
Light beacon
Enclosure rating
Enclosure material
Enclosure door
Net weight
Dimensions (W x H x D)
Power supply
Input voltage
Frequency
Operating temperature
Operating temperature with
Low Temperature Kit*
Storage temperature
Operating humidity
Safety protection
Overcurrent protection
Overvoltage protection*
18
RGB Colour indicator
IP54 / IK10
Aluminium & ABS
Frontal key locked door
55Kg
450 x 1550 x 290 mm
1P+N+PE / 3P+N+PE
230VAC+/- 10% / 400VAC+/-10%
50Hz / 60Hz
-5ºC to +45ºC
-30ºC to +45ºC
-20ºC to +60ºC
5% to 95% Non-condensing
RCD Type A (30mA) / Type B*
MCB (curve C)
Transient surge protector
IEC 61643-1 (Class II)
