5

Hardware and jumper setting

5.1

Power supplies

When the mini module is plugged onto the motherboard, the power is supplied directly by the motherboard. In this
setup, the external power supply input available on the mini module should NOT be used.
When the SPC570SADPT100S mini module is used as a stand-alone board , the external power supplies must
be used (5 V, 3.3 V, 1.25 V).
The following jumpers are used to configure the power supply:
Jumper
VDD_HV_ADC_TSENS voltage configuration:
J1 •
•
VREFH_ADC voltage configuration:
J3 •
•
VDD_HV_PMU_OSC voltage configuration:
J5 •
•
VDD_HV_IO_MAIN voltage configuration:
J6 •
•
External core voltage supply configuration jumper:
•
JP1
•
VDD_LV1 configuration for external 1.25V use:
JP2 •
•
VDD_LV2 configuration for external 1.25 V use:
JP4 •
•
VDD_LV3 configuration for external 1.25V use:
JP5 •
•
UM2868 - Rev 1
Table 1. Power supplies configuration jumpers
Description
1-2: 5 V_LR (linear)
2-3: 5 V_SW (switching)
1-2: 5 V_LR (linear)
2-3: 5 V_SW (switching)
1-2: 5 V_SR
2-3: 3.3 V_SR
1-2: 5V_SR
2-3: 3.3V_SR
Open: core voltage supply not connected to
external 1.25 V
Closed: core voltage supply connected to external
1.25 V
Open: VDD_LV1 not connected to JP1
Closed: VDD_LV1 connected to JP1
Open: VDD_LV2 not connected to JP1
Closed: VDD_LV2 connected to JP1
Open: VDD_LV3 not connected to JP1
Closed: VDD_LV3 connected to JP1
Hardware and jumper setting
Default Position
Figure 10. Overview of
1-2 (5
SPC570SADPT100S mini module - top
V_LR)
C3
Figure 10. Overview of
1-2 (5
SPC570SADPT100S mini module - top
V_LR)
C3
Figure 10. Overview of
1-2 (5
SPC570SADPT100S mini module - top
V_SR)
C2
Figure 10. Overview of
1-2 (5
SPC570SADPT100S mini module - top
V_SR)
C3
Figure 11. Overview of
Open SPC570SADPT100S mini module - bottom
– C4
Figure 11. Overview of
Close SPC570SADPT100S mini module - bottom
– C3
Figure 11. Overview of
Close SPC570SADPT100S mini module - bottom
– C2
Figure 11. Overview of
Close SPC570SADPT100S mini module - bottom
– C2
UM2868
–
–
–
–
page 7/30
