The following picture shows the NEXUS SAMTEC ASP-137973-01 connector schema.
UM2868 - Rev 1
Table 5. JTAG Header 2x7 pins connector pinout
Pin number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Figure 6. NEXUS SAMTEC ASP-137973-01
UM2868
Connectors
Signal
TDI
GND
TDO
GND
TCK
GND
EVTI
N.C.
PORST
TMS
VDD_HV_IO_MAIN
GND
EVTO
N.C.
