1.4.2 SmartLink C device

Size
Working voltage
Typical power consumption
Communication
Working temperature

1.5 Package List (Only for Passenger Vehicle Configuration)

Common accessories are same, but for different destinations, the accessories (such as diagnostic software, testing
connectors) may vary. Please consult from the local agency or check the package list supplied with this tool
together.
No.
1 Display tablet
2 SmartLink C device
3 Power adaptor
4 OBD II extension cable
5 Charging cable (Type A-Micro)
6 Data cable (Type A- Type B)
7 Crossover cable
OBD I adaptor box
8
Cigarette lighter cable
9
Battery clamps cable
10
Non-16pin adaptor cable kit
11

1.5 Package List (Only for Commercial Vehicle Configuration)

Common accessories are same, but for different destinations, the accessories (such as diagnostic software, testing
connectors) may vary. Please consult from the local agency or check the package list supplied with this tool
together.
Item
Indicates the test result.
Connects the SmartLink C device to the OBD II vehicle's
DLC.
Charges the tablet.
Connects the SmartLink C device to PC for J2534
reprogramming.
Connects the SmartLink C device to the modem.
Connects the SmartLink C device and non-16pin adaptor
cable.
Supplies power to the non-16pin connector from the
vehicle's cigarette lighter receptacle.
Supplies power to the non-16pin connector from the
vehicle's battery.
Connects to the vehicle equipped with non-OBD II
management system.
0℃ ~ 50℃
℃
-20 ~ 70℃
204mm x 110mm x 45mm
DC 9 ~36V
≤ 6W
Bluetooth/Wi-Fi or data cable connection
0℃ ~ 50℃
Descriptions
5
X-431 PRO5 User Manual
Qt.
1
1
1
1
1
1
1
(Optional)
(Optional)
(Optional)
(Optional)
