Pin
1 CSI0_EXT1_PWR
2 CSI0_EXT1_PWR
3 CSI0_EXT1_PWR
4 GND
5 CSI0_AVDD
6 CSI0_DVDD
7 CSI0_ACT_VDD
8 CSI0_ACT_VDD
9 CSI0_DOVDD
10 CSI0_DOVDD
11 CAM_MUTE_CONN0_GND
12 CAM0_FLASH_EN
13 CAM1_RST_N
14 CAM1_STANDBY_N
15 GPIO_30_CCI_I2C_SCL0
16 GPIO_29_CCI_I2C_SDA0
17 CAM_MCLK0
18 CAM0_FLASH_TRIG
19 GND
20 MIPI_CSI0_LANE0_N
21 MIPI_CSI0_LANE0_P
22 GND
23 MIPI_CSI0_CLK_N
24 MIPI_CSI0_CLK_P
Open-Q™ 212A Development Kit User Guide
Table 16 Camera Connectors (J5, J4) Pin Out
Signal
MB_VREG_3P3
VREG_L17_2P85
VREG_L2_1P1
VREG_L10_2P85
VREG_L6_1P8
Open-Q 212A Development Kit
Note
