MB_ELDO_CAM1_DVDD
•
MB_ELDO_CAM1_VCM
•
Note 2: See Section 3.8.4 and Section 3.8.5 for setting up the development kit to be powered by a battery
3.8.4 Battery Connector – J300
J300 allows user to connect a single-cell rechargeable Lithium battery pack to power the development kit.
Manufacturer
Part Number
Mating connector
Open-Q™ 212A Development Kit User Guide
Figure 5 SOM Power Source Switch (S300), Up position shown
Figure 6 Battery Connector (J300)
Table 5 Battery Connector (J300) Specification
JST
B6B-XH-A(LF)(SN)
XHP-6
Open-Q 212A Development Kit
Manufactured by JST
21
