Serial Gateway Cable Connections and Pin-outs
KIV7/RS366-DTE
Figure 2-9
shows the KIV7/RS366-DTE cable.
Figure 2-9
KIV7/RS366-DTE Cable
J2 Male (DB-37)
J1 Male (DB-60)
KIV-7 data
J3 Male (DB-25)
RS-366
signaling
Setting Up Your LifeSize Gateway
35
