2.12 Power Supply Specifications

Input Characteristics
Input Voltage Range
Range 1
Range 2
Input Frequency Range
Maximum Input ac Current 4A max at 115Vac
Inrush Current
Efficiency
Output Characteristics
Output Load Range
Voltage Min
+5V 0.5A
+12V 0.45A
-12V
+5Vsb 0.05A
+3V3
Over-Voltage Protection (OVP)
Output Voltage
+5V
+12V
+3.3V
NOTE
The power supply will shut down and latch off for shorting
+5V, +12V, -12V, -5V, or +3.3V. By shorting +5Vsb, the power
supply can latch down or automatically recover when the
fault condition is removed.
ASUS Terminator K7 Barebone System
Min
90V
180V
47 Hz to 63 Hz
2A max. at 230Vac, maximum load
90A max. at 115Vac,
full load cold start at 25°C
70% min. at nominal input,
maximum load
Regulation
Max Min
4.0A -5%
8.2A -5%
0A 0.2A -10%
1.5A -5%
1A 8.0A -5%
Maximum Voltage
6.5V
15.6V
4.3V
Nom Max
115V 135V
230V 265V
Ripple
Max Max
+5% 50mV
p-p
+5% 120mV
p-p
+10% 120mV
p-p
+5% 50mV
p-p
+5% 50mV
p-p
