2.10.2 Power supply specifications

Input characteristics
Input Voltage Range
Range 1
Range 2
Input Frequency Range
Maximum Input AC Current
Inrush Current
Efficiency
Current Harmonic
EPA
Output characteristics
Output Load Range
Voltage Min
+5V 1.5A
+12V 0.5A
-12V 0.05A
+3.3V 0.3A
+5VSB 0.01A
Over-Voltage Protection (OVP)
Output Voltage
+3.3V
+5V
+12V
ASUS Terminator 2 barebone system
Min
90V
180V
47 Hz to 63 Hz
5A max. at 115Vac
3A max. at 230Vac, full load
No hazards to occur and damage components
65% min. at 115Vac and output full load
Meets EN61000-3-2 @ 100Vac/50Hz or
230 Vac/50Hz at full load
50% min. at input 115Vac, 60Hz
Regulation
Max Min
21A -5%
10A -5%
0.8A -10%
14A -5%
2A -5%
Maximum Voltage
4.6V
6.5V
15.6V
Nom Max
115V 132V
230V 264V
Ripple
Max Max
+5% 50mV
p-p
+5% 120mV
p-p
+10% 150mV
p-p
+5% 60mV
p-p
+5% 60mV
p-p
