2.5 Install a Hard Disk Drive
5. Connect a power cable from
the power supply to the power
connector at the back of the
HDD. Use the cable with the
white connector labeled HDD.
6. Connect one end of the IDE
hard disk ribbon cable to the
IDE interface at the back of the
HDD, matching the red stripe
on the cable with Pin 1 on the
IDE interface.
7. Connect the other end of the
IDE ribbon cable to the
primary IDE connector (blue
connector labeled IDE1) on
the motherboard.
ASUS Terminator K7 Barebone System
IDE Ribbon Cable
Red Stripe to Pin 1
Primary IDE Connector
(IDE1)
Power Cable
(HDD)
