2.6 Install a CD-ROM Drive

A CD-ROM drive is an optional item in the Terminator barebone
system. Refer to the instructions in this section if you acquired a
model without a CD-ROM.
Follow these steps to install a
CD-ROM drive.
1. Place the chassis upright.
2. Insert the CD-ROM drive into
the upper 5.25-inch bay.
3. Carefully push the CD-ROM
drive into the bay until its
screw holes align with the
holes on the bay as shown.
4. Secure the CD-ROM with two
screws on each side of the
bay.
24
5.25-inch Drive Bay
CD-ROM Screws
Chapter 2: Basic Installation
