2.9.2 Motherboard Connectors

The figures below show the specific connectors on the motherboard
and the UAEX Extension Module where the front panel cables must
be connected. You must re-connect these cables before replacing
the chassis cover.
PANEL Connector IDELED Lead
USB1 Connector
Front Panel
Connectors
ASUS Terminator K7 Barebone System
Pin 1
FLOUT Lead (for Line Out Cable)
MIC2 Lead (for Microphone Cable)
USB
T: Port0
B: Port1
USB2P
UAEX
®
LOUT
LO2
MIC2
MIC
Keyboard Lock
Speaker
Connector
Power LED
Reset SW
Message LED
ATX Power
SMI Lead Switch*
Requires an ATX power supply.
*
Connect to USB1 Connector
on the Motherboard
Connect to FLOUT Lead
on the Motherboard
Connect to MIC2 Lead
on the Motherboard
29
