2.2 Detach the Drive Frame
3. Place your thumb on the right
edge of the power socket
module, and slide it to the right
until it is completely detached
the module from the rear
panel.
4. Unlatch the drive frame by
pulling it outward.
NOTE
The drive frame has a swivel (hinge-like) edge that is attached to
the main chassis. It is not necessary to completely detach the
drive frame from the chassis when installing components.
5. Carefully lay the drive
frame alongside the main
chassis frame.
18
Drive Frame
Swivel Edge
