3.2 Components

See opposite page for locations.
Processor Support Socket 462 for AMD Athlon/Duron Processor ........ 4
Chipsets VIA VT8364A Integration Single Chip .................... 5
Main Memory Maximum 1GB support (non-ECC)
Expansion Slot 2 Riser PCI Slots .................................................. 17
System I/O IOC_MB Connector ................................................ 1
Audio Features AC '97 Audio Codec ............................................. 16
Network Features LAN Connector (RJ-45) ............................. (Top) 23
Front Panel USB/Audio Board (refer to UAEX layout on p. 29)
Form Factor FlexATX
38
VIA VT686B I/O Controller ................................... 10
2 DIMM Sockets ..................................................... 6
PC133 SDRAM support
1 Floppy Disk Drive Connector ............................. 11
2 IDE Connectors (UltraDMA66 Support) .............. 7
1 Parallel Port ............................................. (Top) 25
1 Serial Port (refer to CGAEX layout on p. 40)
1 VGA Connector ................................. (Bottom) 26
2 USB Connectors (Port 0 & Port 1) ... (Bottom) 21
1 USB Header (Port 2 & Port 3) .......................... 12
1 PS/2 Mouse Connector ............................ (Top) 27
1 PS/2 Keyboard Connector ................. (Bottom)27
Game/MIDI Port (refer to CGAEX layout on p. 40)
Line Out Connector .............................. (Bottom) 24
Line In Connector ................................. (Bottom) 24
Microphone Connector ......................... (Bottom) 24
Modem Connector (internal) ................................ 19
CD Connector (internal) ....................................... 18
Wake-On-LAN Connector .................................... 12
LAN Led ............................................................... 22
Line Out (LOUT) Connector
Microphone (MIC) Connector
LO2 Header
MIC 2 Header
2 USB Connectors (Port 0 & Port 1)
USB2P Header
Power ATX Power Supply Connector ................................ 5
ATX 12V Connector ............................................... 2
Chapter 3: Motherboard Information
Location
