1.1 Front Panel Features

The ASUS Terminator K7 barebone system is composed of the ASUS
A7VC motherboard, a power supply, and a floppy disk drive in the
ASUS TriOptix form factor chassis.
The following figures show the front panel features.
NOTE
The CD-ROM drive and modem card are optional items and
may not come installed in some models.
The lower part of the front panel is a door that covers accessible I/O
features that include two USB connectors (Ports 2&3), a headphone
connector, and a microphone connector. Push the dotted area of the
door to open it and show the connectors as in the above figure.
12
CD-ROM Drive
(optional)
Floppy Drive
Power Button
Power LED
HDD LED
USB Connectors Headphone
Connector
Chapter 1: System Introduction
Microphone
Connector
