Du Pont Cyrel FAST 2000TD Operation Manual page 74

4-16
3. Pull out the loosened material and cut it (1).
4. Then fasten the material coming from the inside of the processor with duct tape to the top cover
above the waste roll (2) as shown in step 5
5. Fasten the cut ends of nonwoven and PET to
the top cover. Each layer separately:
nonwoven first and PET on top of the
nonwoven.
6. Manually turn the chuck bearing of the roll until
the lock is in the "12 o'clock" position.
(The photo is for illustrative purpose only.)
7. Unlock the chuck bearing in the left and right
side of the roll by pressing the chuck bearing's
top-edge outwards (away from the roll).
Operation Manual|Cyrel FAST 2000TD
Maintenance
January, 2020
