Functional description
1-4
The front and rear clamp arms tension
the plate ready for processing.
The front and rear clamp arms will now
synchronize with each other and
rotate the plate around the static drum.
The stack light will flash green.
The plate rotates around the static
drum for the number of revolutions
defined for the selected program.
Close to the nip, the polymer-plate is
preheated by means of an IR heater
and, when it reaches the nip, heated
by the heated roller.
On each revolution the plate makes
around the static drum, the heated
roller will travel to the plate surface
pushing the nonwoven and PET
material onto the plate surface. The
nonwoven material absorbs the
unexposed photopolymer.
